Build your own SQL Database using TypeScript

Introduction

As a developer, I wanted to understand how databases work under the hood, including data structures like B-Trees and Red-Black Trees. Instead of just reading about them, I decided to build my own database from scratch in TypeScript. This blog walks you through how we designed and implemented a realistic SQL-like database engine in TypeScript using:

• A custom parser for simple SQL syntax
• A B-tree-based key-value store
• A file-based storage system for data persistence
• Binary disk persistence
• Write-ahead logging (WAL)
• Support for multiple tables
• Basic SQL operations like SELECT, INSERT, UPDATE, and DELETE

Technologies

Feel free to choose any other alternatives you are familiar with. These are my choices:

• TypeScript - We'll be using TypeScript as our core language but you can go along with GO lang.
• Bun - We'll be using Bun as our runtime environment, which is a fast JavaScript runtime like Node.js but with better performance and built-in TypeScript support.

Project Setup

• Language & Runtime: TypeScript + Bun
• Folder Structure:

LumeDB/
├── src/
│   ├── storage/
│   │   └── pager.ts
│   ├── wal/
│   │   └── wal.ts
│   ├── btree/
│   │   └── btree.ts
│   ├── engine/
│   │   ├── record.ts
│   │   └── query.ts
│   ├── parser/
│   │   └── sqlParser.ts
│   └── main.ts
├── db/
│   ├── data.db
│   └── wal.log
├── package.json
├── tsconfig.json

🧱 Step 1: The Basic CLI Shell

We start with a command-line interface using "readline-sync".

const db = new DB('db/data.db', 'db/wal.log');
while (true) {
  const input = readlineSync.question('> ');
  const result = db.execute(input.trim());
  console.log(result);
}

This REPL-style loop allows us to input SQL commands and interact with the database engine in real time.

Benefits:

• Simple to implement
• Interactive testing

Improvements:

• Use a web API or REPL framework for remote or web-based interaction

🧠 Step 2: Core Database Logic

To handle SQL commands, we need a parser that can interpret basic SQL syntax. We built a custom parser to handle basic SQL commands:

INSERT INTO table VALUES (1, "Alice")
SELECT * FROM table WHERE id = 1
DELETE FROM table WHERE id = 1

This is handled by parseSQL() which returns a structured command object with:

{
  command: 'INSERT' | 'SELECT' | 'DELETE',
  table: 'tableName',
  values: [1, "Alice"],
  where: { id: 1 }
}

Improvements:

• Use a parser generator like PEG.js or ANTLR for extensibility

🌳 Step 3: B-Tree In-Memory Store

We use a simple in-memory B-tree implementation for fast key-value access:

this.btree.insert(key, value);
this.btree.search(key);
this.btree.delete(key);

Benefits:

• Logarithmic access time
• Balanced tree prevents degeneration

Real-World Upgrade:

• Use a B+ tree where leaf nodes are linked for fast range scans
• Store tree nodes in fixed-size pages with serialization

💾 Step 4: Persistent Storage with Pager

Instead of keeping data only in memory, we use a Pager that writes to disk:

const buffer = Buffer.from(`${key}:${value}\n`);
fs.writeFileSync(this.path, buffer);

This simulates pages by storing rows as key:value strings.

Limitations:

• Not real page-based binary format yet
• No offset/index-based updates

Future Work:

• Use fixed-size binary pages (e.g. 4096 bytes)
• Store records at offsets, reuse deleted slots

🔐 Step 5: Write-Ahead Log (WAL)

We implemented WAL to ensure durability:

this.wal.log(`INSERT users 1 Alice`);
// this.wal.flush();

Why WAL?

The Write-Ahead Log (WAL) is crucial for database reliability:

1. Crash Safety: If the database crashes, we can replay the WAL to recover the last consistent state
2. Atomicity: WAL ensures that transactions are either fully committed or fully rolled back
3. Recovery: Provides a way to restore the database to a known good state

Production Suggestions:

For a production-ready WAL implementation:

1. Log Compaction: Periodically compact the WAL by removing redundant entries
2. Table-Specific WALs: Maintain separate WAL files per table for better concurrency
3. Checkpoints: Regularly create checkpoints to reduce WAL replay time

📁 Step 6: Multi-Table Support

Now we support multiple tables by using a Map:

this.tables: Map<string, { btree, pager }>
this.tables.set('users', { btree: new BTree(), pager: new Pager('db/users.db') });

Each table has its own B-tree and Pager file like data.db.users.

Benefits:

• Simulates real RDBMS architecture
• Isolates tables

Improvements:

• Support CREATE TABLE command
• Normalize table schema definition

🔚 Conclusion

We've built a realistic SQL-like database from scratch using simple but scalable techniques:

• SQL command parser
• B-tree structure
• Persistent storage
• WAL logging
• Multi-table support

This is a powerful learning experience for any developer and a stepping stone to more advanced database design.

📌 GitHub Repository

If you'd like a downloadable template of this codebase or want to contribute, here you go

Let me know which part you’d like to explore next: pages, indexes, transactions, or query planner?

Happy hacking! 🛠️
